Adjustment Tips for Cabinet Hinges

1. Longitudinal adjustment

When the cabinet door is uneven, the longitudinal adjustment of the cabinet hinge is an effective solution. The specific steps are as follows:

Open the cabinet door and gently loosen the fixing screws on the hinge, being careful not to completely remove the hinge.

Next, adjust the fixing pads on the upper and lower doors so that the door can move up or down. Make subtle adjustments to ensure that the door gap is consistent.

After the door gap is adjusted to the ideal state, retighten the cabinet hinge fixing screws to ensure stability. Then check the door gap again to ensure the adjustment effect.

2. Horizontal adjustment

If the cabinet door is still misaligned after closing, it may be necessary to adjust the cabinet hinge horizontally. The specific steps are as follows:

Open the cabinet door and loosen the fixing screws on the cabinet hinge seat, which allows the hinge seat to move horizontally.

Using an adjustment rod (or similar tool), gently push the door to the left or right until the door is aligned with the adjacent cabinet door.

After confirming that the doors are aligned, retighten the fixing screws on the hinge seat to ensure that the hinge seat is stable. Then check the door alignment again to ensure the adjustment effect.

3. Height adjustment

When there is a difference in the height of the cabinet door, it can be solved by adjusting the height of the cabinet hinge. The specific operation is:

Open the cabinet door and find the adjustment screw on the cabinet hinge. Use a wrench or other tool to gently turn the adjustment screw so that the door can move up or down.

During the adjustment process, keep observing the height change of the door until the height of the door is consistent with the adjacent cabinet door.

After confirming that the height of the door has been adjusted, retighten the adjustment screw of the cabinet hinge to ensure stability. Then check the height of the door again to ensure the adjustment effect.
